CONTROLS, INSTRUMENTS AND EQUIPMENT
fmo2015-004-032_c
fmo2015-004-013_c
fmo2016-004-001_a
1) Handlebar
The handlebar controls the steering
of the snowmobile. As the handlebar
is rotated to right or left, the skis are
turned right or left to s teer the snow-
mobile.
WARNING
Fast reverse while turning, could
result in loss of stability and con-
trol.
2) Throttle Lever
Throttle Lever
E-TEC Models
Throttle lever is located on the RH side
of handlebar.
Designed to be thumb activated.
When squeezed, it increases the en-
gine speed. When released, engine
speed returns automatically to idle.
_______________
39
