CONTROLS, INSTRUMENTS AND EQUIPMENT
See table below for usual pilot lamps information. Refer to
MONITORING SYS-
TEM
for deta ils on malfunction pilot lamps.
PILOT
LAMP(S) ON
BEEPER DESCRIPTION
—
Low fuel level. One (1) bar left in fuel level display.
Replenish fuel tank as soon as possible.
Long beeps
repeating slowly
Reverse is selected.
—
High beam headlights are selected.
5) SET (S) Button
Button used to naviga te, a djust or reset gauge multifunction display.
In order to memorize settings, engine must be running.
Gauge Features
AVAILABLE INDICATIONS IN DIGITAL D ISPLAY
FUNCTIONS ADVENTURE LX 49 RANGER
A) Odometer
XX
B) Trip meter “A” or “B” X X
C) Trip hour meter
XX
D) Fuel level X X
NOTE: The display is factory preset in M etric units but it is possible to change it to
Imperial units, contact an authorized Lynx dealer for unit settings.
48
