CONTROLS, INSTRUMENTS AND EQUIPMENT
mmo2008-003-020_a
FUEL LEVEL
1. Operating range
E) Heated Grips Heating Intensity
The heating intensity is displayed via
the digital dis pla y.
NOTE: There are nine intensity set-
tings. When released, display will re-
turn to fuel tank level.
mmo2013-004-039_a
HEATING INTEN SITY DISPLAY
1. Less heat
2. More heat
F) Heated Throttle Lever Heating
Intensity
NOTE: The heating intensity is dis-
played via the digital display with the
activation of the throttle lever switch.
When released, display will return to
fuel tank level.
NOTE: There are nine intensity set-
tings.
mmo2013-004-040_a
HEATING INTEN SITY DISPLAY
1. Less heat
2. More heat
Gauge Setup
Unit Selection (KM/H vs MPH)
The units can be set in metric or imperi-
als. RefertoanauthorizedLynxdealer.
11) Analog/Digital Gauge
(Standard)
E-TEC Models
WARNING
Reading the gauge digital display
can distract from the operation of
the vehicle, particularly from con-
stantly scanning the environment.
Gauge Description
mmo2008-003-013_g
ANALOG/DIGITAL GAUG E (STAN DA RD)
1. Speedometer
2. Tachometer (RPM)
3. G auge Digital Display
4. Pilot Lamps
5. G au ge SET “S” button
50
