CONTROLS, INSTRUMENTS AND EQUIPMENT
A) Odometer
Records the total distance travelled.
Press the SET (S) button to select
odometer mode.
mmo2008-003-013_c
1. Odometer mode
B) Trip Meter A or B
Trip meters records distance travelled
since it has been reset.
Press the SET (S) button to select trip
meter (TRIP A/TRIP B) mode.
mmo2008-003-013_c
1. Trip meter (TRIP A/TRIP B) mo de
Press and hold the SET (S) button to re-
set.
mmo2008-003-013_d
C) Trip Hour Meter
Records vehicle running time when
the electrical system is activated since
it has been reset.
Press the SET (S) button to select trip
hour meter (HrTRIP) mode.
mmo2008-003-013_c
1. Trip hour mete r (H rTRIP) mode
Press and hold the SET (S) button to re-
set.
mmo2008-003-013_d
D) Fuel Level
Bar gauge that continuously indicates
the amount of fuel left in the fuel tank.
mmo2008-003-020_a
FUEL LEVEL
1. Operating range
_______________
53
