CONTROLS, INSTRUMENTS AND EQUIPMENT
mmo2008-007-018
RH PORTION OF G AU GE
3) Multifunction Digital Display
mmo2007-009-066_u
MULTIFUNCTIO N AN ALOG/DIGITAL GAUGE
1. M ultifu nction display
The multifunction display is used to:
– Display the WELCOM E message
on power up
– Display the KEY recognition mes-
sage
– Provide various indications as se-
lected by the operator
– Activating or changing various func-
tions or m odes of operation
– Display scrolling messages of func-
tion activation or system fault
s
– Display fault codes.
When the information center is first
powered up, the numerical displ
ay de-
faults to the last selected indication.
WARNING
Never adjust or set functions on
the multifunction gauge while rid-
ing the vehicle.
4) Pilot Lamps and Messages
mmo2008-003-024_a
TYPICAL — PILOT LAMPS
_______________
55
To Next Page
