CONTROLS, INSTRUMENTS AND EQUIPMENT
mmo2007-009-066_w
O) Message Display
mmo2007-009-066_c
1. Message display
Refer to
PILOT LAMPS AND MES-
SAGES
in th is sec tion for details on
usual messages.
Refer to
MONITORING SYSTEM
for
details on malfunction and D.E.S.S. re-
lated messages.
P) Engine Coolant Temperature
Bar gauge that indicates the engine
coolant temperature.
During normal operation, the bars
should not exceed approximately the
middle of the gauge.
NOTICE
If engine overheats, stop
vehicle in a safe place. Refer to
TROUBLESHOOTING section.
mmo2012-006-902_a
Q) E-TEC Engine Storage Mode
Displays "O IL" when the storage mode
procedure is initiated.
R) Lap Record Mode
With this mode, vehicle speed, engine
revolutions per minute (RPM) and a
preselected function in display 1 can
be recorded at the same time during a
period of time defined by the operator.
Also, a pos sibility of nine (9) different
sessions (laps) can be recorded for a
maximum total of 2.5 minutes.
mmo2007-009-066_h
LAP RECORD MODE
1. L ap r ecord mode display
2. Sessions (laps)
3. Vehicle speed
4. Engine revolution per minute (RPM)
5. Preselected function
To Activate Lap Record Mode:
1. Press the SET (S) button to select
the odometer mode in display 3.
2. Press and hold SET (S) button for 2
seconds to activate mode, REC will
be displayed to indicate that record
mode has been selected.
_______________
65
