= fl ash = on = off
Error Indicators Error On/Off
Line
Repeat Data
Clear
Cut Test
1 Sram error
2 Dram error
3 Check media, drum, or X motor
4 Check media or Y motor
6.4 Error Indicators
If mechanical problems or failure during operations happen, the ERROR LED will turn on. Please follow the
instruction below to solve the problem. If the plotter still cannot work, please inform your dealer of these types
of error indicators or have your plotter serviced.
Error 1 and 2.
At this moment, please contact your dealer.
Error 3. Check media drum, or X motor
This message indicates that there might be a problem on the X axis. Check if the drum is working well and if
the media is well loaded. Correct the problem and re-power on to reboot system.
Error 4. Check media, or Y motor
This message indicates that there might be an obstruction to carriage relating to a problem on the Y axis. Correct
the problem and re-power on to reboot system.
6. Troubleshooting 6-4
