Introduction
This document is an unocial user guide for N anoV N A. The URL is https://cho.github.io/ N anoV N A-manual/.
It is managed by the github repository .
Please send Pull-request when there are corrections such as discrepancies with the latest rmware.
It is also available in PDF format on the Releases page on GitHub.
https://github.com/cho/ N anoV N A-manual/releases
What is N anoV N A
There are several types of N anoV N A hardware and this document covers the following hardware:
ttrftech version (original) ttrftech/ N anoV N A
hugen version hugen/ N anoV N A-H
These hardware have almost the same components on the circuit, and common rmware is available.
What is required for operation
You need at least the following:
N anoV N A body
SMA LOAD  Ω
SMA SHORT
SMA OPE N
