7RUTXHZUHQFKHVPD\KDYHDQDGDSWHUDWWDFKHGWR
KHOSUHDFKDEROWRUQXW8VHWKHIROORZLQJIRUPXODWR
UHFDOFXODWHWKHUHDGLQJRIWKHWRUTXHZUHQFK
Formula:
Example: ( with “E” as plus dimension)
T = 135 lb. In.
Y = Unknown
L = 10.0 In.
E = 1.5 In.
Desired Torque
Original Length
Extension
Y = 117 lb In.
Final reading on torque wrench
Adapter Drive
Centerline
Wrench Drive
Centerline
Torque Wrench
Handgrip Centerline
(Predetermined)
E
L
= Y
T x L
L + E
=
135 x 10
10 + 1.5
Y = = 117.39
1350
11.5
)LJXUH
