SPECIFICATIONS
INSTALLATION INSTRUCTIONS
NOTE: Ensure to check all parts are present.
A: Synthetic leather with foil and zipper
B: Control panel
C: Spa pool
D: Temp barrier mat
E: Digital lock
F: Filter cartridge
G: Drainage hose
H: Repair kit
I: Inflatable bladder
J: Manometer + Inflation Hose
A. B. C.
D. E.
G.
J.
H.
Style No.
Seating capacity
2
Power rated
Heater
Massage air blower
polyester laminated
PVC withfoil and
inflatable bladder
Synthetic leather with foil
and inflatable bladder
110~120V, 60Hz
650 L/171 gallon 930 L/245 gallon
2 4
4-6
Top lid
Outside Dimensions
Inside Dimensions
Bubble Spa
NOTE: Drawings for illustration purpose only in this manual. Actual product may vary. Not to scale.
B-090 B-100
B-110
B-120
B-121
B-112
B-141
B-150
B-151
B-152
Shape Square Oval Round Round
B-130
B-131
B-132
B-140
+ 2
4
polyester laminated
PVC withfoil and
inflatable bladder
B-091
Square
+ 2
1.58 m/62” 1.85 m/73”
1.45 m/57”
1.28 m/50.5”
0.68 m/27” 0.68 m/27”
Water Capacity
(Approx.)
Height
675W x 2
500W
110~120V, 60Hz
675W x 2
500W
700 L/184 gallon
1.80 m/71”
1.40 m/55”
0.70 m/28”
110~120V, 60Hz
675W x 2
500W
930 L/245 gallon
2.04 m/80”
1.60 m/63”
0.70 m/28”
110~120V, 60Hz
675W x 2
500W
550 L/145 gallon
1.86x1.25 m/73.5”x49.5”
1.46x0.85 m/57.5”x33.5”
0.68 m/27”
110~120V, 60Hz
675W x 2
500W
Power Cable Length 3.1 m/10 feet 3.1 m/10 feet 3.1 m/10 feet 3.1 m/10 feet3.1 m/10 feet
Filter pump
AC 24 V/50 W AC 24 V/50 W AC 24 V/50 W AC 24 V/50 WAC 24 V/50 W
B-110/B-120 polyester
laminated PVC withfoil and
inflatable bladder
B-121/B-130/B-131/B-132/
B-140 Synthetic leather with
foil and inflatable bladder
B-112 polyester laminated
PVC withfoil and inflatable
bladder
B-141/B-150/B-151/B-152
Synthetic leather with
foil and inflatable bladder
