EXTERNAL DIMENSIONS unit: mm (inch)
50 (1.97)
72 (2.83) [3.3 (.13)]
80 (3.15)
20
(.79)
35.4 (1.39)
60 (2.36)
72 (2.83)
7.8 (.31)
CLAMP
(top & bottom)
DIN RAIL
35mm wide
2–4.5 (.18) dia.
MTG HOLE
25 (.98) deep
14–M3.5
SCREW
•When mounting, no extra space is needed between units.
•Input shunt resistor attached for current input.
56
14
11
1
1015
3
2
7
9
8
103 (4.06)
132 (5.20)
12 (.47)
INPUT RESISTOR
(model: REM)
12
4
