M3 Mobile OX10 User Manual

Basic usage
19
QWERTY keypad layout
Button
Description
SCAN
Used to scan while scanner program is running.
Navigation
Move to up/right/down/left.
Soft1 / Soft2
Use specific command or menu.
Send / Windows
Used to make a call or to open ‘Start’ menu in orange mode.
End / OK
Used to end a call or to confirm changes in orange mode.
Characters
Used to input characters or to execute functions.
Back space
Deletes previous input data
Shift
Used to input uppercase letters.
Function
Activate specific function.
Power
Long press: Turns on / off the device.
Short press: Enters Sleep / Wake up Mode.
Backlight toggle
Toggles the LCD backlight.
Short press: Reduces the backlight level to 5% and/or turns on
the backlight
Long press: Turns off the backlight completely
Orange function
Enables orange mode.
Orange ring: Orange mode is effective only once.
Orange circle: Orange mode is effective until turned off.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
