BEKABELING / WIRING
Nr. ID kleur omschrijving colour description
1 NC1 oranje relais 1 NC orange relais 1 NC
2 NO1 blauw relais 1 NO blue relais 1 NO
3 COM1 paars relais 1 COM purple relais 1 COM
4 GND zwart - (GND) black - (GND)
5 AC1 rood + (AC1) red + (AC1)
6 OPEN1(LED) geel drukknop naar GND, LED
commando in Wiegand stand
yellow push button to GND, LED
command in Wiegand mode
7 D1 wit Wiegand uitgang D1 white Wiegand output D1
8 D0 groen Wiegand uitgang D0 green Wiegand output D0
9 NC2 wit/oranje relais 2 NC white/orange relais 2 NC
10 NO2 wit/blauw relais 2 NO white/blue relais 2 NO
11 COM2 wit/paars relais 2 COM white/purple relais 2 COM
12 AC2 grijs AC2 grey AC2
13 OPEN2 bruin drukknop naar GND relais 2 brown push button to GND relais 2
14 BELL_B roze deurbel pink doorbell
15 BELL_A roze deurbel pink doorbell
CABLAGE / VERDRAHTUNG
Nr. ID couleur description Farbe Beschreibung
1 NC1 orange relais 1 NC orange Relais 1 NC
2 NO1 bleu relais 1 NO blau Relais 1 NO
3 COM1 violet relais 1 COM lila Relais 1 COM
4 GND noir - (GND) schwarz - (GND)
5 AC1 rouge + (AC1) rot + (AC1)
6 OPEN1(LED) jaune bouton poussoir à GND,
commande LED en Wiegand
position
gelb Taster zu GND, LED Befehl in
Wiegand Position
7 D1 blanc sortie de Wiegand D1 weiß Wiegand Ausgang D1
8 D0 vert sortie de Wiegand D0 grün Wiegand Ausgang D0
9 NC2 blanc/
orange
relais 2 NC weiß/orange Relais 2 NC
10 NO2 blanc/
bleu
relais 2 NO weiß/blau Relais 2 NO
11 COM2 blanc/
voilet
relais 2 COM weiß/lila Relais 2 COM
12 AC2 gris AC2 grau AC2
13 OPEN2 marron bouton poussoir à GND relais 2 braun Taster zu GND Relais 2
14 BELL_B rose sonnette pink Türklingel
15 BELL_A rose sonnette pink Türklingel
FLEXESS AQUA CODETABLEAU EN PASLEZER / FLEXESS AQUA KEYPAD AND CARDREADER
DIGICODE ET LECTEUR DE BADGES FLEXESS AQUA / FLEXESS AQUA CODE TASTATUR UND LESER
CS500
050220
