MXBP501 SERIES SYSTEM WIRING DIAGRAM
Template 56377 10-05-12
56549_97_A 10-07-13
4
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2,
Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. © Copyright 2009 Balboa Water Group.
Hardware Setup
F3 10A 250V
F2 3A 250V
F6 0.3A 250V
J101
J100
J42
J39
J54
J56
J57
J40
J49
J32
J51
J41
J53
J12
J38 J37 J48
J50
J56
J52
J19 J18
J35 J34 J36
J55
J43
J24 J14
F5 30A
K3
TB1
K5
K6
K2
K1
K4
OZONE
J47
A/V
J8 J21
PUMP 1
NOT USED
3
3
2
2
(UNFUSED)
2
1
1
S1
F4 3A 250V
K12
K7
J15
J33
J45
J109
J22
TEMP SENSORS
J16 J17
J28 AUX FRZ
BLOWER
J5
AUX
LIGHT
ON
1
6
GND
J46
HEATER
120V 120V
240V
12VAC-B 12VAC-A
J44
J13
J20
BLWR/P3
J23
SERIAL
J108
EXPANDER
J25
J31
J26
J30
J25=HTR1 J26=HTR2
J27=HTR3 J30=TEST
J31=CE HTR SEL
J27
T1
10-07-13
TORQUE RANGE FOR HEATER
CONNECTIONS: 30 TO 35 IN. LBS.
FOR SUPPLY CONNECTIONS,
USE CONDUCTORS SIZED ON THE
BASIS OF 60°C AMPACITY BUT
RATED MINIMUM OF 90°C.
TORQUE RANGE FOR
MAIN TERMINAL BLOCK:
27-30 IN. LBS.
A DISCONNECTING MEANS MUST BE INSTALLED WITHIN SIGHT FROM
THE EQUIPMENT AND AT LEAST 5 FEET (1.52 M) FROM THE
INSIDE WALLS OF THE POOL, SPA, OR HOT TUB.
CONNECT ONLY TO CIRCUITS PROTECTED BY A CLASS A GFCI.
USE COPPER CONDUCTORS ONLY.
EMPLOYER UNIQUEMENT
DES CONDUCTEURS DE CUIVRE.
#6 AWG MIN. WIRE= 90°
MXBP501X PN 56549
HTR
DISBL
J29
VAC
OPTIONAL EXPANDER BOARD KIT 51264 IS ONLY
INSTALLED IN SETUPS 1, 2, 3, 5, & 6.
PUMP 2
J1
W1
J7
RIGHT
EXPANDER
BOARD
J6
EXPANDER
X-P332
F1 30A
LOCATION DEVICE VOLTS AMPS FROM TO FROM TO
J1 ON RT 2/1 SPD 240V 12A W1 ON GROUP 3 J6 ON J56
EXPANDER PUMP 2 MAX EXPANDER J34 EXPANDER
LOCATION DEVICE VOLTS MAX AMPS FROM TO
J8 2-SP PUMP 1 240V 10A MAX J50 J48-AREA 3
J14 BLOWER 240V 4A MAX J32 J36-AREA 3
J14
1-SP PUMP 3 OPT 240V 10A MAX J32 J36-AREA 3
J15 SPA LIGHT 10V 1A
J21
J24 OZONE 240V 1A
OZONE LINE 1 CONNECTION J51 J37-AREA 3
AV PLUG TV / AV 120V 2A J49 J53-AREA 1
J46 HEATER 240V 5.5 kW
MOVE WIRE TO CONNECT J2O TO J12 FOR PUMP 3 IN SETUP 3
ALL UNUSED SWITCHES SHOULD BE OFF
TEST MODE OFF
DON’T ADD 1 HS PUMP W/HTR
DON’T ADD 2 HS PUMPS W/HTR
1 MIN HTR COOLDOWN (ELEC)
SPECIAL AMPERAGE RULE OFF
STORE SETTINGS*
TEST MODE ON
ADD 1 HS PUMP WITH HEAT
ADD 2 HS PUMPS WITH HEAT
5 MIN HTR COOLDOWN (GAS)
SPECIAL AMPERAGE RULE ON
MEMORY RESET*
1
2
3
4
5
6
ON POSITIONS1 SWITCH #OFF POSITION
*SWITCH # 6 SHOULD BE SET TO OFF UPON FINAL INSTALLATION.
5.5 kW HEATER
SENSOR A
SENSOR B
TP (MAIN) PANELS
J33 or J45
AUX
J5 (A1-A4)
WIFI
TRANSCEIVER
J33 OR J45
WHITE
BLACK
RED
GRN
