In more detail...
MPWP1800-3 by MacAllister
EN
Product functions
Holders
Spray gun holder
Use the upper spray gun holder (9) to store the spray gun (8) (Fig. 12).
Accessories holder
Accessories (soap tank, nozzle, extension lance) can be stored at the back of the
product. (Fig. 12).
Transportation handle
> Press the lock-off button (2) to unlock
the transportation handle (1) (Fig. 13,
step 1).
> Move the transportation handle (1) to
required position (high/low position)
(step 2).
> Ensure the handle is engaged properly
and the lock-off button goes back to
default position (step 3).
1
2
1.
3.
2.
Fig. 13
On/off switch
> Set the on/off switch (5) in its “1” position to start the product (Fig. 14, A).
> Set the on/off switch (5) in its “0” position to switch off the product (Fig. 14, B).
5
A B
Fig. 14
