FEARLESS1000 part list
remote on/off board
Resistor RT-1/8W-510 2 R6 2 R10 R19
RT-1/8W-5.1K 1 R6 1 R14
RT-1/8W-10K 3 R6 3 R11 R15 R16
RT-1/8W-15K 1 R6 1 R12
Resistor RT-1/8W-27K 1 R6 1 R13
Capacitor CD110-16V-10µF 3 E5/5 3 EC01 EC02 EC03
IC 13700D 1 DIP16 1 IC01
Junction wire J8 2 J8 2 JP1 JP2
Switch SK-22F03G9 1 SK-22F03G9 1 SW01
Telephone socket XJY-PCB-17 (4P/grey) 1 TELE-4P 1 J02
5P wire 2.54-5T(80mm/plug+socket) 1 5 pin wire 1 J01
PCB(remote on/off board) TQ7.820.757 (TQ5.948.580) 1 1
remote volume control board
Resistor RT-1/4W-10K 1 R10 1 R1
Potentiometer RD915N-2A1-B10K(metal handle) 1 WR0911N 1 VRE1
knob 11
LED LED(Green/Φ3) 1 LED1 1 LED1
telephone socket XJY-PCB-17 (4P/black) 1 TELE-4P 1 REMOTE11
Telephone line 4P (1to4/black) 1 1
PCB(remote board) TQ7.820.755 (TQ5.948.578) 1 1
