MAC Audio FEARLESS 1000 User Manual

FEARLESS1000 part list
C3198 2 TR1 2 Q306 Q307
C3200 5 TR1 5 Q204 Q203 Q208 Q201A Q201B
C3478 1 TR1 1 Q213
C3502 1 TR2-T 1 Q210
C4793 1 TR2-T 1 Q214
C5198 5 TR3 5 Q227 Q223 Q224 Q225 Q226
D1047 1 TR3 1 Q216
MPSA42 1 TR1 1 Q406
Audion MPSA92 1 TR1 1 Q405
Transistor IRFZ44N 8 TR2 8 M1 M3 M5 M7 M8 M6 M4 M2
IC 4558D 2 DIP8 2 U101 U102
4741D 1 DIP14 1 U103
PC817 1 DIP4 1 U302
IC TL494CN 1 TL494CN 1 U301
Torroid power supply TQ4.723.084 (Φ48) 2 BYQ-Z4 2 T301 T302
Inductance TQ4.757.028 2 L1 2 L302 L301
(Φ10×25magnetic pillar/wire diameterΦ2.5/)
RCA AV4-8.4-21E (red/golden/red washer) 2 AV4-8.4-21E 2
RCA AV4-8.4-21E (black/golden/black washer) 2 AV4-8.4-21E 2
3pin terminal JSZ3A-29(golden) 1 JSZ3A-29 1 TER1
3pin terminal JSZ4A-23(golden) 1 JSZ4A-23 1 TER2
Fuse holder BXS3-09 1 BXS3-08 1 FUSE
Fuse 30A 3 3
Switch SK-22F03G9 2 SK-22F03 2 SW2 SW3
5 pin socket 2.54-5T 1 1 P3
3 pin socket 2.54-3T 1 CON2.54-3T 1 P4
3 pin wire 2.54-3T(60mm/single plug) 1 1
3 pin wire 2.54-3T(80mm/double wire plug) 1 1 P1A→P1B
3 pin wire 2.54-3T(190mm/double wire plug) 1 1 P2A→P2B
Junction strip TQ7.755.009 (171MX) 2 G40 2 JJ1 JJ2
Page 4

MAC Audio FEARLESS 1000 Specifications

General

Brand	MAC Audio
Model	FEARLESS 1000
Category	Car Amplifier
Language	English
