Technical Specifications
LED Indicators
Warranty
The Limited Warranty Statement can be found on the website
www.paradox.com/terms.
Patents
Your use of the Paradox product signifies your acceptance of
these terms and conditions.
One or more of the following US patents may apply: 7046142,
6215399, 6111256, 6104319, 5920259, 5886632, 5721542,
5287111, 5119069, 5077549 and RE39406 and other pending
patents may apply. Canadian and international patents may also
apply.
© 2015 Paradox Security Systems (Bahamas) Ltd. All rights
reserved. Specifications may change without prior notice.
Specification Description
Power Input AC: 6 Vac (500 mA) to 16.5
Vac (200 mA)
DC: 5 Vdc (500 mA) to 24 Vdc
(200 mA)
RF Frequency 433 MHz, 868 MHz
Current
Consumption
Relay ON: 45-160 mA
Relay OFF: 6-20 mA
PGM 1 N.O./N.C. 5A, 28V relay
Relay’s Maximum
Voltage
60 Vdc/28 Vac
Operating
Temperature
0°C to 50°C (32°F to 122°F)
Range 35 m (115 ft.) with MG6250
70 m (230 ft.) with MG5000 /
MG5050 / RTX3
Compatibility • MG6250, MG5000 and
MG5050
• SP5500, SP6000, SP7000
and SP65
(RTX3 is required)
• EVO192 and EVOHD
(RTX3 is required)
Dimensions 12.5 cm x 4.6 cm x 2.5 cm
(4.9 in. x 1.8 in. x 1.0 in.)
Certification For updated information, visit
www.paradox.com
LED Description
RX Receiving information
TX Sending information
RSSI
Indicates signal strength
Flash twice Strong signal
Flash once Weak signal
No flash No signal
Relay Indicates that the relay is ON
