PARTS SUPPLIED
The parts required for positioning the dishwasher are in plastic bags. Check that all of the
following parts are contained in the plastic bags.
The dishwasher comes with a manual bag containing:
User manual, Installation manual
DISHWASHER PARTS BAG 1
This dishwasher bag comes with the following parts:
Test Strip
Hose Clamp
DISHWASHER PARTS BAG 2
Steam Protection Foil
Side Trim Strips (Left)
Side Trim Strips (Right)
DISHWASHER PARTS BAG 3
Screws Ø 5/32” x 19/32” (Ø 4mm x 15mm)
Mounting Bracket Left
Mounting Bracket Right
DISHWASHER PARTS BAG 4
(MODEL DEPENDING)
Toe Kick Bracket
Screws Ø 5/32” x 7/32” (Ø 4mm x 6mm)
Plinth Fixing Metal
Adjustable Plinth
Adjustable Plinth Metal (130mm)
Adjustable Plinth Metal (80mm)
Plinth Locking Pins
DISHWASHER PARTS BAG 5
(MODEL DEPENDING)
Long Legs
To Next Page
