Magnavox MDR515H User Manual

17
EN
EN
Recording Playback EditingIntroduction
Connections
Basic Setup Function Setup Others
Español
Supplied cables used in this connection are as follows:
• RF coaxial cable x 1
• RCA audio cable (L/R) x 1
Please purchase the rest of the necessary cables at your local store.
IN
OUT
ANTENNA
rear of this unit
VHF / UHF
antenna
cable TV
company
or
RF coaxial
cable
RF coaxial
cable
ANT. IN
This connection is for
TV pass through only
IN
IN
OUT
VIDEO
IN
AUDIO IN
(
L1
)
S-VIDEO S-VIDEO
AUDIO OUT
OUT
L
R
VIDEO
OUT
Y
ANTENNA
R
L
COAXIAL
AUDIO OUT
L
R
Y
COMPONENT
VIDEO OUTPUT
RCA audio cable
(Green)
(Blue)
(Red)
Y
P
B
/CB
PR
/CR
COMPONENT
VIDEO IN
(Green)
(Blue)
(Red)
AUDIO IN
L
R
RCA component
video cable
VIDEO
OUT
CONNECTION
Connecting to a TV Using Component Video Out jacks
• HDMI outputs t
h
e vi
d
eo / au
d
io signa
l
s wit
h
out converting to ana
l
og signa
l
s.
• No audio connection is re
q
uired
.
• High Speed HDMI cable (also known as HDMI category 2 cable) is recommended
f
or better compatibility.
• Use an HDMI cable with the HDMI logo (a certi
f
ied HDMI cable)
f
or this connection
.
IN
OUT
ANTENNA
HDMI OUT
HDMI IN
rear of this unit
VHF / UHF
antenna
cable TV
company
or
ANT. IN
This connection is for
TV pass through only
RF coaxial
cable
RF coaxial
cable
Do not tilt the connector when inserting it into the HDMI jack, and make sure the
shapes of the jack and the connector are matched.
IN
IN
OUT
VIDEO
IN
AUDIO IN
(
L1
)
S-VIDEO S-VIDEO
AUDIO OUT
OUT
L
R
VIDEO
OUT
Y
ANTENNA
R
L
COAXIAL
HDMI cable
Supplied cables used in this connection are as follows:
• RF coaxial cable x 1
Please purchase the rest of the necessary cables at your local store.
Connecting to a TV with an HDMI Compatible Port
E2S02UDMDR515HF7ENv1.indd17E2S02UDMDR515HF7ENv1.indd17 2010/08/179:04:162010/08/179:04:16

Magnavox MDR515H Specifications

Power

power supply voltage	120 V
power supply frequency	60 Hz

Ports & Interfaces

front connections	Analog Audio Left/Right In, Composite Video (CVBS) In, DV In, S-Video In
rear connections	Analog audio Left/Right out, Component Video output, Composite video (CVBS) output, Digital coaxial out, HDMI output, S-Video out, Analog audio Left/Right in
additional rear connections	Composite video (CVBS) input, S-Video in, RF In, RF Out

Weight and Dimensions

set dimensions	420 x 59 x 290 mm
set weight	3.4 kg
packaging dimensions	520 x 147 x 413 mm
weight including packaging	4.6 kg
