Magneti Marelli ATF EXTRA PRO - Page 24

24 USER MANUAL
9.2 Replacing printer paper
To change the paper roll, proceed as follows:
Open the printer panel
as shown in figure 1;
Position the paper roll and ensure that the paper unrolls in the right direction as
shown in figure 2;
Pull out some of the
paper as shown in figure 3 and close the panel;
The printer is ready.
Figure 1
Figure 3
Figure 2
