XLS .52A AIRCRAFT ENGINE DIMENSIONAL DRAWING

DIMENSIONS

A 3-3/8"

B 3-1/2"

C 4-3/4"

D 2-7/8"

E 3-1/2"

F 11/16"

G 1-1/8"

H 1-7/16"

I 1-3/4"

J 2-1/16"

K 1-1/16"

L 1-7/16"

M 1-3/4"

N 7/16"

Use this drawing to help you determine engine mounting requirements.

Drawing is not to scale and is generic in nature.
