B-8

35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08

Splitting Between Engine & Transmission

12. Dismantle the Starter motor.

13. Dismantle the instrument cluster & disconnect

the wiring harness to the instrument cluster.

14. First remove the steering wheel cap and steering

wheel nut. Remove the steering wheel by

loosening nut and use steering wheel puller to

remove the steering wheel.

15. Dismantle the steering column cover, disconnect

the wiring harness to PTO engaging switch.

16. Dismantle the scuttle cover.

17. Disconnect the clutch, brake Vertical linkage

connections below front platform.

18. Disconnect the F/R cable from HSU mounting

bracket.

19. Remove the wiring harness from firewall clamps

completely.

20. Dismantle the Fire wall assembly from front

platform.

21. Dismantle hood mounting support bracket.

22. Dismantle Dust cover from clutch hosing.
