B-12
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Transmission & Rear Axle Assembly
Removing of Control Levers Knob
19. Remove the PC, DC, Range, Speed lever knobs
& slow fast valve knob.
20. Remove the differential lock foot pedal.
21. Remove the isolator mounting bolts from Rear
platform.
22. Dismantle the rear platform.
23. Dismantle the isolator mounting bracket from
Rear Axle.

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
