DIAGNOSTIC MANUAL MAN-00201
QUANTO EMS SEP 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,
are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,
will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
`
HOW TO USE THIS MANUAL
If the DTC code is known, then go to the Index of DTC code, and click on the group under which the
DTC appears. The codes/groups are hyperlinked to the respective trouble shooting chart/pages.
The following is the structure of the EMS Diagnostic Manual –
DTC and its description
Component location in the vehicle
Normal operation of the system
DTC detecting conditions
Probable causes
Lamp status
DTC reaction on vehicle
Healing Condition
Connector layout
Circuit Schematic
Connector views and information
Diagnostic tree
Always use the diagnostic manual along with the vehicle’s wiring manual (MAN-00200 ).
OVER VIEW OF THE CAN NETWORK
