DIAGNOSTIC MANUAL MAN-00201
QUANTO EMS SEP 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,
are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,
will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
`
ECU
Connector
Pin no
Function Connected To
Pin no
59 SIGNAL
CLOCK SPRING 8-CHANNEL (CRUISE
CONTROL)
F
60 SIGNAL ACCELERATOR PEDAL MODULE 2
6
61 SIGNAL ACCELERATOR PEDAL MODULE 1
4
65 CAN LOW DLC CONNECTOR
2
66 CAN HIGH DLC CONNECTOR
3
67 SIGNAL STARTER RELAY
85
71 SIGNAL T15 INPUT
T15
73 POWER LOW SIDE INJECTOR 1
2
74 SIGNAL (Negative) CRANK SHAFT SENSOR
2
75 SIGNAL HFM SENSOR (Air Flow Ref signal)
2
76 GROUND RAIL PRESSURE SENSOR
1
77 SIGNAL HFM SENSOR (Air Temp Signal)
4
78 GROUND BOOST PRESSURE SENSOR
2
80 SIGNAL BRAKE MAIN SWITCH
2
81 GROUND CLOCK SPRING
G
82 GROUND ACCELERATOR PEDAL MODULE 2
5
83 GROUND ACCELERATOR PEDAL MODULE 1
3
89 GROUND HIGH PRESSURE PUMP
1
91 GROUND AC COMP RELAY
1
92 GROUND BOOST PRESSURE ACTUATOR
1
59 SIGNAL
CLOCK SPRING 8-CHANNEL (CRUISE
CONTROL)
F
60 SIGNAL ACCELERATOR PEDAL MODULE 2
6
61 SIGNAL ACCELERATOR PEDAL MODULE 1
4
65 CAN LOW DLC
2
66 CAN HIGH DLC
3
67 SIGNAL STARTER RELAY
85
