DIAGNOSTIC MANUAL MAN-00201
QUANTO EMS SEP 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present document,
are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra & Mahindra Ltd.,
will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
`
STEP 1
Connect the smart tester
Turn the ignition ON
Initialise the diagnostic tool
Record the DTC and clear
Turn ignition OFF
Turn ignition ON
Crank the engine
Verify if P0336 is present?
Is P0336 present?
Intermittent problem exists
Refer the intermittent problem
inspection procedure
STEP 2
Ignition OFF
Crankshaft speed sensor wiring
harness connector (C37)
DISCONNECTED
EMS ECU wiring harness
connector (C4) DISCONNECTED
Check the continuity between
pin 2 of the crankshaft speed
sensor wiring harness connector
and pin 74 of the EMS ECU
wiring harness connector
I
Is the continuity
exists?
Examine the open circuit of
crank shaft speed sensor signal
wire
Replace the wiring harness
Clear the DTC and verify
STEP 3
Ignition OFF
Check and correct if any loose
connections noticed in the
crankshaft speed sensor wiring
harness connector
Check for proper fitment of the
crank shaft speed sensor
mounting bolt
Is the bolt fitted
properly?
STEP 4
Go to STEP 5
Ignition OFF
Crankshaft speed sensor wiring
harness connector (C37)
DISCONNECTED
Remove the crank shaft speed
sensor
Check for any damage on the
crankshaft speed sensor front
face
Is there any
damage?
Suspect for any foreign particles
presence.
Identify the cause and rectify
Replace the crankshaft speed
sensor with a new one
Clear the DTC and verify
Fix the bolt properly and tighten
it to the torque specified
Clear the DTC and verify
NOYES
NOYES
NOYES
YESNO
To Next Page
