11 Vehicle Controls
o
Brake System Indicator – red light on steady when the brake
fluid level is below the minimum level or the parking brake is
set.
o
Wait To Start Indicator – yellow light on steady in IGN & ACC
position. Engine intake air heater is on due to engine tem-
perature, wait for light to go out before cranking.
l Fuel Gauge:
o
4 bars – 87% or more fuel in tank
o
3 bars – 62% or more fuel in tank
o
2 bars – 38% or more fuel in tank
o
1 bar – 13% or more fuel in tank
o
Bottom Bar Outlined Only – 12% or less fuel in tank
Figure 1. Multifunction gauge
© 2018 Mahindra Vehicle Sales and Service, Inc. All Rights Reserved. 29
