mHAWK IMMOBILISER TROUBLESHOOTING CHART
IMMOBILISER TROUBLESHOOTING CHART
No communication from EMS
Disturbance in CAN wiring (short
to +/-, terminating resistor)
EMS not getting IGN
input/Defective EMS
Check wiring & rectify/Replace
EMS
ICU response not acceptable to ECM
Disturbance in CAN wiring (short
to +/-, terminating resistor)
Perform ECM - ICU learning
Signal from EMS ECU is not acceptable
to ICU.
Disturbance in CAN wiring (short
to +/-, terminating resistor)
Perform ECM - ICU learning
ICU didn’t receive acknowledgement
from ECM.
Disturbance in CAN wiring (short
to +/-, terminating resistor)
Erase the DTC and check if it is
coming again
No communication from ICU.
Disturbance in CAN wiring (short
to +/-, terminating resistor) or
power/ground lines.
Replace ICU &Perform ECM -
ICU/ICU - Key learning
