Operating Instructions MA 42
Operating_Instructions_8100460-6_MA42_e_15a 7 8100460-6 1/15
3.4 Rear panel connections
Figure 1– Rear view of the MA 42
1: Power switch
10: CD Input
2: Power socket 100-240VAC / 50-60Hz
11: Speaker left channel
3: Network socket
12: Speaker right channel
4: USB out socket
13: Bone conduction receiver
5: USB in socket
14: Insert phone left channel
6: Pat patient response switch socket
15: Insert phone right channel
7: Talk Back microphone socket
16: Phone left channel (headphone)
8: Mic live voice microphone socket
17: Phone right channel
9: Mon monitor phone output socket
Place the MA 42 on a stable counter or table. Plug the power cord into the
power socket on the rear panel. Connect all accessories with the adequate
sockets as shown above. Plug the power cord into a grounded outlet.
Turn on the instrument with the power switch which is located at the right side
of the MA 42. The device performs its initialization and auto calibration. Please
wait till the test screen appears, this can take up to 60 sec. If an error is detected
the test is stopped and a description of the error is shown on the display. In this
case please contact your local dealer or service.
11
13
14
16
15
12
9
10
8
7
6
5
4
2
1
3
17
