8 Part No. 5000893Dimensions, Clearances & Product Specification
Models
Mersey Super Medway Super Thames
Output kW 22.7 23.3 23.3
Input kW 30.3 30.3 30.3
Gas rate m∆/h 2.91 2.91 2.91
Burner Pressure** mbar 12.5 12.5 12.5
Burner Injector Size mm 1.2 1.2 1.2
Pilot Injector Size mm 0.27 0.27 0.27
Appliance Weight
Installed with Water kg 18.6 18.6 18.5
Water Capacity litre 0.75 0.75 0.75
Flow Rate l/min 6.5 (at 50 °C rise)
Maximum Pressure Head bar 13
Minimum Pressure
Head Requirement at
Water Heater bar 1 (Under Flow Conditions)
Connections - Gas mm 15 (Copper Tail)
- Water mm 15 (Compression)
Telescopic Flue Kits mm (in) 100 - 150 (4 - 6) Sales Code 31/10321
150 - 230 (6 - 9) Sales Code 31/10322
230 - 380 (9 - 15) Sales Code 31/10323
380 - 610 (15 - 24) Sales Code 31/10324
SeDuct Flue Kit Sales Code 31/12968
Finish White stoved paint with contrasting chassis
Classifications CAT 1
2
H
C
11
, C
21
,
CE Pin No. 87AP121 87AP125 87AP124
Notes:
* Additional external pipework and fittings may affect the resistance and must be taken into account on
installation.
** The nominal burner pressure should be 12.5 mbar and will only be obtained if the appliance inlet pressure
is correct at 20 mbar even when the appliance is running at full heat input. The meter should be capable of
passing 3 m∆/h of natural gas plus the requirements of any other gas appliances. See also Section 3.2, page
12.
Conversions: kW to Btu/h = kW x 3412.14, m∆/h to ft∆/h = m∆/h x 35.31, mbar to in wg = mbar x 0.4
Product Specification
Heat Input figures are
quoted as gross.
