Mainstays 9509CHWM User Manual

Pg 10 of 38
1-800-892-3986 IS9052
Step 3.1-MIDDLE - Cabinet Assembly for MIDDLE DOOR installation option.
Magnet holes facing DOWN
on the fixed shelf (B).
B
B
C-L
C-R
Magnet holes facing UP
on the fixed shelf (B).
finished edge
Magnet holes facing UP
on the top shelf (A).
A
C-L
C-R
Step 3.2-MIDDLE - Cabinet Assembly for MIDDLE DOOR installation option.
H 1
H 2
x 4
x 8
H 1
H 2
H 2
H 2
H 2
H 2
• NOTE: Do NOT fully tighten side panels (C-L and C-R) to the fixed shelves (B).
Now skip to step 4, page 12.
LOCATOR HOLES
