Pg 3 of 38
1-800-892-3986 IS9052
A
Top and Bottom Shelf
2
B
Fixed Shelf
2
C
Top Side Panel ( C-R right and C-L left)
2
D
Door
2
List of Parts
E
Back Panel
1
F
Support Rail / Trim
2
G
Bottom Side Panel
2
H
Optional Leg Extension
2
A
A
B
B
C-R
E
F
F
G
C-L
D
D
G
LOCATOR HOLES
H
H
CL LEFT TOP PANEL
CL RIGHT TOP PANEL
