Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(1) Cam Lock (Qty. 24+1 extra) (2) Cam Bolt (Qty. 24+1 extra)
(3) M15 x 40 mm Wood Dowel (4) M6 x 30 mm Wood Dowel
(Qty. 8+1 extra) (Qty. 40+2 extra)
(5) 5/16" x 40 mm Bolt (6) Lock Washer (7) Flat Washer
(Qty. 8+1 extra) (Qty. 8+1 extra) (Qty. 8+1 extra)
(8) Plastic Cap (Qty. 4+1 extra) (9) Shelf Pin (Qty. 16+1 extra) Hex Wrench (Qty. 1)
Glue Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(Qty. 1) (Not included for White Finish) (Included in plastic bag)
Tools required: Hex wrench (provided), Phillips screwdriver and hammer (not provided).
