Vibration Damper on Camshaft
Repair / Disassembly and reassembly
A5.05. 04.09.01.02
15000
M20
en / 30.05.2000 IB021607 2/2
04
Ĺ
2. Reassembly
2.1 Clean contact faces of dampers (1and 2), washers (4 and 5) and cover disk (6).
2.2 Check bores (9) of cover disk (6) and bore (8) of washer (5) for free flow and clean, if neces-
sary.
2.3 Lubricate thread and contact face of cylinder head screws (3 and 7) with Molykote paste
„G-Rapid“.
2.4 Mount cover disk (6).
2.5 Tighten cylinder head screws (7) with a torque of
M = 60 Nm
2.6 Slip-on damper (1) as shown in the illustration.
2.7 Place washer (5) and align it so that the bores (8 and 9) coincide.
Attention:
The free flow of bores (8 and 9) is absolutely necessary to ensure a proper function.
2.8 Mount both dampers (2) with washer (4), cylinder head screws (3) and sleeves (10) in ac-
cordance with the illustration.
2.9 Tighten cylinder head screws (5) with a torque of
M = 60 Nm
