13
15 16
14
Footpad (1)
Dragoon Foot (2)
1:1
M4×8mm Screw (3)
Dragoon main part (1)
1:1
Nylon Lock Nut 4mm (5)
M4×16mm Screw (5)
1:1
M4×8mm Screw (2)
The dragoon's body has a
frosted surface facing
outwards, and the smooth
surface contacts the legs.
The direction of the two servo
gears should be consistent
with the figure.
Plastic Spacer 4 x 7 x 2 (2)
Repeat steps 1 ~ 14 to complete the construction of the remaining
three legs of the Dragoon.
