Mallory E-SPARK - Install Rubber Plug; Install Wire Grommet and Lubricate Wires

MALLORY IGNITION 550 MALLORY WAY, CARSON CITY, NV 897014
Step 10
Insert the rubber plug into the existing grommet hole
(Figure 12). This is a tight fit and you may need to pull
it through. Once it is in position, cut the bushing off
flush on the inside (Figure 13).
Step 11
Install the wire grommet. Lubricate the wires with light
oil. Run the wires through the grommet and out of the
distributor housing (see Figure 14).
FIGURE 11
FIGURE 12
FIGURE 13
FIGURE 14
Grommet
E-SPARK Plate
Assembly
Connector
