14
Rear:
Mic delay control 1 11 Audio Line Out
Mic EQ: treble 2 12 Line In
Mic EQ: bass 3 13 AUX In
Mic 3: Volume 4 14 FM antenna jack
Mic 3: Input jack 5 15 Digital Out (coax)
HDMI Out 6 16 Video Out
Audio Out 7 17 S-Video Out
Component Video Out 8 18 Digital optical Out
Speaker R Out 9 19 AC In
Speaker L Out 10 20 Power ON/OFF
