MAM RS3 - RS3 Connections and Power

Connections of the RS3
• $&ýìëý92/7
External Power Supplyýõ12 Volt, AC, 700 mA)
•
INPUT (Front), IN (Rear)
Audio input of the RS3. If both sockets are connected, only the input
on the front will be active.
• Man/EXT IN (Front), Modulation (Rear)
An external voltage (0-10V) for common modulation of the bandpass
frequencies. If both sockets are connected, only the input on the front side is
active.
• OUT (Rear)
Stereo Output of the RS3
