Weights and measures;

Mambo 8

• cabinet size 25cm high by 25cm wide by 20cm deep (approx)

• weight 6.9 kg

• the loudspeaker is 8inch, 225W rms rated, 95 dB / Watt @ 1 metre sensitivity

• the power amplifier is rated at 180 W rms (continuous sine wave)

Mambo 10

• cabinet size 30cm high by 30cm wide by 25cm deep (approx)

• weight 8 kg

• the loudspeaker is 10inch, 250W rms rated, 97 dB / Watt @ 1 metre sensitivity

• the power amplifier is rated at 180 W rms (continuous sine wave)

Inputs, outputs and controls.

Fig. 1 top panel controls

• 1/4" mono jack instrument input

• gain / volume

• treble

• middle

• bass

• power indicator

Fig. 2 rear panel controls
