MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 5.10
Page 1 of 2
MAN Diesel
198 91 23-0.0 MAN B&W S65ME-C8.2-GI
Counterflanges
Reference Cyl. no.
Flange Bolts
Description
Diam. PCD Thickn. Diam. No.
A 5-8 Flange for pipe 139,8x6,6 Starting air inlet
B 5-8 For reduction station Male G1” Control air inlet
D 5-8 See Fig. 5.10.02 Exhaust gas outlet
E 5-8 See Fig. 5.10.03 Venting of lube oil discharge pipe turbocharger
EB 5-8 See Fig. 5.10.03 Cooling air TC (MET MB)
X 5-8 175 140 26 M16 8 Fuel oil inlet
F 5-8 175 140 26 M16 8 Fuel oil outlet
K
5-6 235 200 16 M16 8
Jacket cooling water inlet
7-8 265 230 18 M16 8
L
5-6 235 200 16 M16 8
Jacket cooling water outlet
7-8 265 230 18 M16 8
M 6-8 95 75 10 M10 4 Cooling water deaeration
N
5 235 200 16 M16 8
Cooling water inlet to air cooler (Central cooling water)
6-8 320 280 20 M20 8
P
5 235 200 16 M16 8
Cooling water outlet from air cooler (Central cooling water)
6-8 320 280 20 M20 8
N
5-7 265 230 16 M16 8
Cooling water inlet to air cooler (Sea water)
8 320 280 20 M20 8
P
5-7 265 230 16 M16 8
Cooling water outlet from air cooler (Sea water)
8 320 280 20 M20 8
S 5-8 See special drawing of oil outlet System oil outlet to bottom tank
RU
5-6 385 345 22 M20 12
Lubricating & cooling oil (system oil)
7-8 430 390 22 M22 12
RW 5-8 155 130 14 M12 4 System oil back flussing
RY 5-8 220 180 95 M16 8 Inlet hydraulic oil supply
RZ 5-8 320 280 20 M20 8 Outlet hydraulic oil supply
AB
TCA66 265 230 18 M16 8
Lubricating oil outlet from turbochargers
TCA77 200 165 16 M16 8
TCA88 235 200 16 M16 8
MET60MA 265 230 18 M16 8
MET66 265 230 18 M16 8
MET71 190 155 14 M16 8
MET83 235 200 16 M16 8
AC 5-8 95 75 12 M10 4 Lubrication oil inlet to cylinder lubricators
AD 5-8 115 90 12 M12 4 Fuel oil return from umbrella sealing
AE 5-8 115 90 12 M12 4 Drain from bedplate / cleaning of turbocharger
AF 5-8 115 90 12 M12 4 Fuel oil to drain tank
AG 5-8 115 90 12 M12 4 Drain oil from piston rod stuffing boxes
AH 5-8 Coupling for 30 mm pipe Fresh cooling water drain
AK 5-8 Coupling for 30 mm pipe Inlet cleaning air cooler
AL
1xAC 120 95 12 M12 4
Outlet air cooler cleaning / water mist catcher
2xAC 130 105 14 M12 4
AM
1xAC 120 95 12 M12 4
Outlet air cooler to chemical cleaning tank
2xAC 130 105 14 M12 4
AN 5-8 Coupling for 30 mm pipe Water inlet for cleaning turbocharger
AP 5-8 Coupling for 30 mm pipe Air inlet for dry cleaning of turbocharger
AR 5-8 130 105 14 M12 4 Oil vapour discharge
AS 5-8 Coupling for 30 mm pipe Cooling water drain air cooler
