MAN B&W 5.12
Page 3 of 3
MAN Diesel
MAN B&W S65ME-C/-GI 198 48 94-2.3




#ENTREæOFæ
MAINæBEARING
$ETAIL¬$
!
!
3ECTION¬""
665
65
Taper 1:100
8
6
3
54
7
2
1
147
Space for hydraulic
tightening jack
about ø230
about 370
Side chock brackets, option: 4 82 622 includes:
1. Side chock brackets
Side chock liners, option: 4 82 620 includes:
2. Liner for side chock
3. Lock plate
4. Washer
5. Hexagon socket set screw
End chock bolts, option: 4 82 610 includes:
1. Stud for end chock bolt
2. Round nut
3. Round nut
4. Spherical washer
5. Spherical washer
6. Protecting cap
End chock liner, option: 4 82 612 includes:
7. Liner for end chock
End chock brackets, option: 4 82 614 includes:
8. End chock bracket
Fig. 5.12.02b: Profile of engine seating, end chocks, option: 4 82 620
Fig. 5.12.02c: Profile of engine seating, end chocks, option: 4 82 610
178 57 34-8.0
178 57 25-3.0
