MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 6.03
Page 2 of 4
MAN Diesel
MAN B&W S65ME-C8.2-GI
198 87 21-5.1
List of Capacities for 6S65ME-C8.2-GI-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA77-21
1 x A275-L
1 x MET71MB
1 x TCA77-26
1 x A180-L37
1 x MET83MB
1 x TCA77-21
1 x A275-L
1 x MET71MB
1 x TCA77-26
1 x A180-L37
1 x MET83MB
Pumps
Fuel oil circulation m³/h 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0 8.0
Fuel oil supply m³/h 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7 4.7
Jacket cooling m³/h 143 143 143 143 143 143 143 143 143 143 143 143
Seawater cooling * m³/h 530 533 540 544 550 560 525 526 529 539 541 544
Main lubrication oil * m³/h 340 330 340 340 340 340 340 330 340 340 340 340
Central cooling * m³/h - - - - - - 407 410 416 417 423 431
Scavenge air cooler(s)
Heat diss. app. kW 7,020 7,020 7,020 7,290 7,290 7,290 6,980 6,980 6,980 7,250 7,250 7,250
Central water flow m³/h ------ 250 250 250 260 260 260
Seawater flow m³/h 343 343 343 356 356 356 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 1,280 1,300 1,350 1,280 1,320 1,390 1,280 1,300 1,350 1,280 1,320 1,390
Lube oil flow * m³/h 340 334 339 340 336 342 340 334 339 340 336 342
Central water flow m³/h ------ 157 160 166 157 163 171
Seawater flow m³/h 187 190 198 187 194 203 - - - - - -
Jacket water cooler
Heat diss. app. kW 2,490 2,490 2,490 2,490 2,490 2,490 2,490 2,490 2,490 2,490 2,490 2,490
Jacket water flow m³/h 150 150 150 150 150 150 143 143 143 143 143 143
Central water flow m³/h ------ 157 160 166 157 163 171
Seawater flow m³/h 187 190 198 187 194 203 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 10,750 10,770 10,820 11,020 11,060 11,130
Central water flow m³/h ------ 407 410 416 417 423 431
Seawater flow m³/h - - - - - - 525 526 529 539 541 544
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0
Compressor cap. m³ 420 420 420 420 420 420 420 420 420 420 420 420
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5
Compressor cap. m³ 210 210 210 210 210 210 210 210 210 210 210 210
Other values
Fuel oil heater kW 136 136 136 135 135 135 136 136 136 136 136 136
Exh. gas temp. ** °C 250 250 250 230 230 230 250 250 250 230 230 230
Exh. gas amount ** kg/h 138,965 138,965 138,965 147,558 147,558 147,558 138,965 138,965 138,965 147,558 147,558 147,558
Air consumption ** kg/s 37.8 37.8 37.8 40.2 40.2 40.2 37.8 37.8 37.8 40.2 40.2 40.2
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01f: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
