MAN B&W 6.03
Page 3 of 4
MAN Diesel
MAN B&W S65ME-C8.2-GI
198 87 21-5.1
List of Capacities for 7S65ME-C8.2-GI-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA77-26
1 x A280-L
1 x MET83MB
1 x TCA88-21
1 x A280-L
1 x MET83MB
1 x TCA77-26
1 x A280-L
1 x MET83MB
1 x TCA88-21
1 x A280-L
1 x MET83MB
Pumps
Fuel oil circulation m³/h 9.4 9.4 9.4 9.3 9.3 9.3 9.4 9.4 9.4 9.3 9.3 9.3
Fuel oil supply m³/h 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5 5.5
Jacket cooling m³/h 167 167 167 167 167 167 167 167 167 167 167 167
Seawater cooling * m³/h 618 624 634 637 640 650 613 615 618 630 631 634
Main lubrication oil * m³/h 400 400 400 410 400 400 400 400 400 410 400 400
Central cooling * m³/h - - - - - - 475 480 488 490 492 500
Scavenge air cooler(s)
Heat diss. app. kW 8,190 8,190 8,190 8,510 8,510 8,510 8,150 8,150 8,150 8,460 8,460 8,460
Central water flow m³/h ------ 292 292 292 304 304 304
Seawater flow m³/h 400 400 400 416 416 416 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 1,490 1,530 1,600 1,510 1,530 1,600 1,490 1,530 1,600 1,510 1,530 1,600
Lube oil flow * m³/h 400 396 402 405 396 402 400 396 402 405 396 402
Central water flow m³/h ------ 183 188 196 186 188 196
Seawater flow m³/h 218 224 234 221 224 234 - - - - - -
Jacket water cooler
Heat diss. app. kW 2,910 2,910 2,910 2,910 2,910 2,910 2,910 2,910 2,910 2,910 2,910 2,910
Jacket water flow m³/h 175 175 175 175 175 175 167 167 167 167 167 167
Central water flow m³/h ------ 183 188 196 186 188 196
Seawater flow m³/h 218 224 234 221 224 234 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 12,550 12,590 12,660 12,880 12,900 12,970
Central water flow m³/h ------ 475 480 488 490 492 500
Seawater flow m³/h - - - - - - 613 615 618 630 631 634
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0
Compressor cap. m³ 420 420 420 420 420 420 420 420 420 420 420 420
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5 2 x 3.5
Compressor cap. m³ 210 210 210 210 210 210 210 210 210 210 210 210
Other values
Fuel oil heater kW 159 159 159 158 158 158 159 159 159 158 158 158
Exh. gas temp. ** °C 250 250 250 230 230 230 250 250 250 230 230 230
Exh. gas amount ** kg/h 162,126 162,126 162,126 172,151 172,151 172,151 162,126 162,126 162,126 172,151 172,151 172,151
Air consumption ** kg/s 44.1 44.1 44.1 46.9 46.9 46.9 44.1 44.1 44.1 46.9 46.9 46.9
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01g: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
