MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 6.03
Page 4 of 4
MAN Diesel
MAN B&W S65ME-C8.2-GI
198 87 21-5.1
List of Capacities for 8S65ME-C8.2-GI-TII at NMCR
Seawater cooling Central cooling
Conventional TC High eff. TC Conventional TC High eff. TC
1 x TCA88-21
1 x A280-L
1 x MET83MB
1 x TCA88-21
1 x A285-L
2 x MET66MB
1 x TCA88-21
1 x A280-L
1 x MET83MB
1 x TCA88-21
1 x A285-L
2 x MET66MB
Pumps
Fuel oil circulation m³/h 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7 10.7
Fuel oil supply m³/h 6.3 6.3 6.3 6.2 6.2 6.2 6.3 6.3 6.3 6.2 6.2 6.2
Jacket cooling m³/h 191 191 191 191 191 191 191 191 191 191 191 191
Seawater cooling * m³/h 707 710 720 725 732 745 701 702 705 718 721 725
Main lubrication oil * m³/h 460 450 460 460 450 460 460 450 460 460 450 460
Central cooling * m³/h - - - - - - 544 547 555 557 563 574
Scavenge air cooler(s)
Heat diss. app. kW 9,350 9,350 9,350 9,720 9,720 9,720 9,310 9,310 9,310 9,670 9,670 9,670
Central water flow m³/h ------ 334 334 334 347 347 347
Seawater flow m³/h 457 457 457 475 475 475 - - - - - -
Lubricating oil cooler
Heat diss. app. * kW 1,710 1,730 1,790 1,710 1,750 1,840 1,710 1,730 1,790 1,710 1,760 1,840
Lube oil flow * m³/h 460 451 457 460 452 460 460 451 457 460 452 460
Central water flow m³/h ------ 210 213 221 210 216 227
Seawater flow m³/h 250 253 263 250 257 270 - - - - - -
Jacket water cooler
Heat diss. app. kW 3,310 3,310 3,310 3,310 3,310 3,310 3,320 3,320 3,320 3,320 3,320 3,320
Jacket water flow m³/h 200 200 200 200 200 200 191 191 191 191 191 191
Central water flow m³/h ------ 210 213 221 210 216 227
Seawater flow m³/h 250 253 263 250 257 270 - - - - - -
Central cooler
Heat diss. app. * kW - - - - - - 14,340 14,360 14,420 14,700 14,750 14,830
Central water flow m³/h ------ 544 547 555 557 563 574
Seawater flow m³/h - - - - - - 701 702 705 718 721 725
Starting air system, 30.0 bar g, 12 starts. Fixed pitch propeller - reversible engine
Receiver volume m³ 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0 2 x 7.0
Compressor cap. m³ 420 420 420 420 420 420 420 420 420 420 420 420
Starting air system, 30.0 bar g, 6 starts. Controllable pitch propeller - non-reversible engine
Receiver volume m³ 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0 2 x 4.0
Compressor cap. m³ 240 240 240 240 240 240 240 240 240 240 240 240
Other values
Fuel oil heater kW 182 182 182 181 181 181 182 182 182 181 181 181
Exh. gas temp. ** °C 250 250 250 230 230 230 250 250 250 230 230 230
Exh. gas amount ** kg/h 185,287 185,287 185,287 196,744 196,744 196,744 185,287 185,287 185,287 196,744 196,744 196,744
Air consumption ** kg/s 50.4 50.4 50.4 53.6 53.6 53.6 50.4 50.4 50.4 53.6 53.6 53.6
* For main engine arrangements with built-on power take-off (PTO) of a MAN Diesel & Turbo recommended type and/or torsional
vibration damper the engine's capacities must be increased by those stated for the actual system
** ISO based
For List of Capacities for derated engines and performance data at part load please visit http://www.mandieselturbo/ceas/index.htm
Table 6.03.01h: Capacities for seawater and central systems as well as conventional and high efficiency turbochargers stated at NMCR
