MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 8.02
Page 2 of 2
MAN Diesel
198 83 49-0.1
MAN B&W 70-60ME-C/-GI engines
Safety and accumulator block
Hydraulic Power Supply unit
Engine driven pumps
Electrically driven pumps
Hydraulic oil
MM
Filter unit
Redundance filter
Main filter
Back-flushing oil
RW
RU
Lube oil to turbocharger
To hydraulic cylinder unit
Crosshead bearings & piston Main bearings
System oil outlet, S
Axial vibration damper
Aft Fore
PI 8108 PI 8108 LOP
WT 8812 I AH Y
WT 8812
LS 1234 AH
FS 8114 AL Y
TI 8113
TE 8106 I AH Y
TI 8106
TS 8107 Z
LS 1236 AH ZLS 1235 AH
XS 8150 AH *
TE 8112 I AH
TI 8112
Connected to cylinder frame or framebox
TE 8113 I AH Y
To 2nd order moment compensator (fore end if applied)
To chain drive (if applied)
PT 8108 I AL Y PS 8109 Z XS 8151 AH * XS 8152 A *
* According to DUN 23.2007
The letters refer to list of ‘Counterflanges’
The item no. refer to ‘Guidance Values Automation’
The piping is delivered with and fitted onto the engine
Fig. 8.02.01: Engine driven hydraulic power supply unit and lubricating oil pipes
Hydraulic Power Supply Unit, Engine Driven, and Lubricating Oil Pipes
178 48 134.4b
