Lubricating oil tank operating conditions
The lubricating oil bottom tank complies with the
rules of the classification societies by operation
under the following conditions:
Angle of inclination, degrees
Athwartships Fore and aft
Static Dynamic Static Dynamic
15 22.5 5 7.5
Table 8.06.01b: Lubricating oil tank, with cofferdam
If space is limited, however, other solutions are
possible. Minimum lubricating oil bottom tank vol-
ume (m
3
) is:
4 cyl. 5 cyl. 6 cyl. 7 cyl. 8 cyl.
15.2 18.5 22.4 26.1 30.0
Note:
When calculating the tank heights, allowance has
not been made for the possibility that a quantity of
oil in the lubricating oil system outside the engine
may be returned to the bottom tank, when the
pumps are stopped.
If the system outside the engine is so designed
that an amount of the lubricating oil is drained
back to the tank, when the pumps are stopped,
the height of the bottom tank indicated in Table
8.06.01b has to be increased to include this quan-
tity.
Cylinder
No.
Drain at
cyl. No.
D0 D1 H0 H1 H2 H3 W L OL Qm
3
4
2-4 225 450 995 450 90 300 400 6,000 895 15.3
5
25 250 475 1,075 475 95 400 500 6,750 975 18.7
6
25 275 550 1,155 550 110 400 500 8,250 1,055 24.7
7
257 300 600 1,210 600 110 400 600 9,750 1,110 30.7
8
258 325 650 1,275 650 120 400 600 10,500 1,175 35.0
