MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 8.07
Page 1 of 2
MAN Diesel
MAN B&W 70-60MEC/-GI 198 42 61-5.6
Hole diam.: 55 mm
To be equipped with flame screen
if required by class rules
Drain cowl
Inside diameter of drain pipe: 10 mm
This pipe to be
delivered with the engine
Deck
Inside diam. of pipe: 80 mm
To drain tank
To be laid with inclination
Venting from crankcase inside
diam. of pipe: 50 mm
AR
Crankcase Venting and Bedplate Drain Pipes
198 97 101.4c
Fig. 8.07.01: Crankcase venting
Fig. 8.07.02: Bedplate drain pipes, aft-mounted HPS
525 29 54-1.3.0
Cyl. 1
AE
Drain, turbocharger cleaning
Drain, cylinder frame
Fore
Hydraulic Cylinder Unit
LS 4112 AH
Hydraulic power supply unit
LS 1235 AH
LS 1236 AH Z
Startup /
Backup
pumps
Hydraulic
oil filter
AE

MAN B&W S65ME-C8.2-GI-TII Specifications

General

Brand	MAN B&W
Model	S65ME-C8.2-GI-TII
Category	Engine
Language	English
