MAN B&W 16.01
Page 7 of 10
MAN Diesel
MAN B&W ME/MEC/-GI engines 198 79 24-7.2
Mechanicalhydraulic System with Electrically Driven HPS
Fig. 16.01.02b: Mechanicalhydraulic System with electrically driven Hydraulic Power Supply, 300 bar, common supply.
Example from S90/80ME-C engine
515 75 49 -1.1.1
M
M
M
M
Main filter
To AE
Safety and
accumulator block
RW
Backflushing oil
Filter unit
RU
Stepup gear
To AE
Main tank
Distributor block
Return to tank
Lubricating
and cooling
oil pipes
Alarm box
Alarm box
ME lubricator
PT 1204n ZL
PT 12043 ZL
Return oil
standpipe
FIVA
with pilot valve
Return to
tank
Fuel oil drain
Fuel oil inlet
Fuel pump
Exhaust
Valve
Actuator
Exhaust valve
Fuel valves
Hydraulic piston
High pressure pipes
Umbrella
sealing
Hydraulic
piston
Activation
piston
Fuel oil outlet
X
F
AD
Oil supply to
hydraulic 'pushrod'
for exhaust valve
I
Hydraulic pushrod
Hydraulic
piston
HPS unit
ZV 8204 C
ZT 8203 C
LS 8208 C
ZT 4111 C
Return to
tank
Return to
tank
LS 4112 AH
PT 12011 C
PT 12012 C
PT 12013 C
ZV 1243 C
PT 12042 ZL PT 12041 ZL
ZT 4114 C
XC 1231 AL
PS 12041 C PS 12042 C PS 12043 C
PS 1204n C
LS 1235 AH
LS 1236 AH Z
The letters refer to list of ‘Counterflanges’
Th item No. refer to ‘Guidance Values Automation’
