MAN B&W S65ME-C8.2-GI-TII User Manual

MAN B&W 17.07
Page 1 of 1
MAN Diesel
MAN B&W S65ME-C8.2/-GI 199 02 08-5.0
External Forces and Moments, S65ME-C8.2/-GI Layout point L
1
Table 17.07.01
a) 1st order moments are, as standard, balanced so as to obtain equal values for horizontal and vertical moments for
all cylinder numbers.
c) 5 and 6-cylinder engines can be fitted with 2nd order moment compensators on the aft and fore end, reducing the
2nd order external moment.
No of cylinder : 5678
Firing type : 1-4-3-2-5 1-5-3-4-2-6 1-7-2-5-4-3-6 1-8-3-4-7-2-5-6
External forces [kN] :
1. Order : Horizontal 0 0 0 0
1. Order : Vertical 0000
2. Order : Vertical 0000
4. Order : Vertical 0000
6. Order : Vertical 0 14 0 0
External moments [kNm] :
1. Order : Horizontal a)
197 0 117 394
1. Order : Vertical a)
197 0 117 394
2. Order : Vertical 2,266 c) 1,576 c) 458 0
4. Order : Vertical 14 106 301 122
6. Order : Vertical 1010
Guide force H-moments in [kNm] :
1 x No. of cyl. 1,786 1,398 1,102 824
2 x No. of cyl. 206 94 88 92
3 x No. of cyl. - - - -
Guide force X-moments in [kNm] :
1. Order :
162 0 97 324
2. Order :
436 303 88 0
3. Order :
370 668 731 937
4. Order :
69 534 1,517 616
5. Order :
0 0 138 1,738
6. Order :
40 0 24 0
7. Order :
302 0 0 54
8. Order :
198 138 11 0
9. Order :
11 220 25 22
10. Order :
0 55 156 0
11. Order :
4 0 95 122
12. Order :
300624
13. Order :
250164
14. Order :
21700
15. Order :
04014
16. Order :
21540
